Approximation properties by shifted knots type of α-Bernstein–Kantorovich–Stancu operators


Through the real polynomials of the shifted knots, the α-Bernstein–Kantorovich operators are studied in their Stancu form, and the approximation properties are obtained. We obtain some direct approximation theorem in terms of Lipschitz type maximum function and Peetre’s K-functional, as well as Korovkin’s theorem. Eventually, the modulus of continuity is used to compute the upper bound error estimation.

1 Introduction and preliminaries

In 1912, it was established that for all continuous function g on the interval \([0,1]\) the classical Bernstein polynomials \(B_{s}(g;z)\) converge uniformly to g (see [9]). In 1968, for the real parameters α, β such that \(0\leq \alpha \leq \beta \), Stancu introduced another variant of Bernstein polynomial known as Bernstein–Stancu operators \(B_{s,\alpha ,\beta}(g;z)\) such that (see [28])

$$ B_{s,\alpha ,\beta}(g;z)=\sum _{i=0}^{s} \binom{s}{i} z^{i}(1-z)^{s-i}g \left (\frac{i+\alpha}{s+\beta}\right ), $$

where \(z\in [0,1]\), \(z\in \mathbb{N}\), and Stancu in his investigation showed that \(B_{s,\alpha ,\beta}\) is uniformly convergent to the continuous function g in \([0,1]\).

In the year 2017, Chen et al. [12] proposed the generalization of Bernstein operators with shape parameter \(\alpha \in [0,1]\). These operators are defined as follows:

$$ B_{s,\alpha}(g;z)=\sum _{i=0}^{s} g_{i} \tilde{b}_{s,i}(\alpha ;z),\quad z\in [0,1], $$

where \(g\in C[0,1]\) and \(g_{i}=g\left ( \frac{i}{s}\right )\). For \(s>2\), the polynomial \(\tilde{b}_{s,i}(\alpha ;z)\) of degree s is defined by \(\tilde{b}_{1,0}(\alpha ;z)=1-z\), \(\tilde{b}_{1,1}(\alpha ;z)=z\), and

$$\begin{aligned} \tilde{b}_{s,i}(\alpha ;z) &= \binom{s-2}{i}(1-\alpha )z^{i}(1-z)^{s-i-1} + \binom{s-2}{i-2}(1-\alpha )z^{i-1}(1-z)^{s-i} \\ &+ \binom{s}{i}\alpha z^{i}(1-z)^{s-i}, \end{aligned}$$

and the binomial coefficient \(\binom{s}{i}\) is given by

$$ \binom{s}{i}=\textstyle\begin{cases} \frac{s!}{i!(s-i)!} & \text{if } 0\leq i\leq s , \\ 0 & \text{otherwise}.\end{cases}$$

Mohiuddine et al. [19] provided the Kantorovich variant of operators (2). Numerous authors have repeatedly presented various generalizations of the aforementioned operators and established approximation results. For instance, Schurer modification of operators (2) was covered in Özger et al. [23].

In a more recent work, the Bernstein–Stancu polynomials are presented using shifted knots with new parameters in the following way (see [13]):

$$ S_{s,\alpha ,\beta}(g;z)=\left (\frac{s+\beta _{2}}{s}\right )^{s} \sum _{i=0}^{s} \binom{s}{i} \left (z- \frac{\alpha _{2}}{s+\beta _{2}}\right )^{i} \left ( \frac{s+\alpha _{2}}{s+\beta _{2}}-z\right )^{s-i}g\left ( \frac{i+\alpha _{1}}{s+\beta _{1}}\right ), $$

where \(z\in [\frac{\alpha _{2}}{s+\beta _{2}}, \frac{s+\alpha _{2}}{s+\beta _{2}}]\) and \(\alpha _{i}\), \(\beta _{i}\), \(i=1,2\), are positive real numbers provided \(0\leq \alpha _{2} \leq \alpha _{1} \leq \beta _{1} \leq \beta _{2}\). Researchers in approximation processes have recently developed Bernstein type operators; for example, we choose [1, 21, 29]. The relevant results for this article have been studied in various functional spaces such as Phillips operators via q-Dunkl generalization [2], Approximation by α-Baskakov-Jain type operators [15], Durrmeyer-type generalization of μ-Bernstein operators [16], modified λ-Bernstein polynomial [7], Kantorovich q-Baskakov operators [6], Szász–Durrmeyer operators [5], Bézier bases with Schurer polynomials [22], Stancu-type λ-Schurer [4], λ-Bernstein operators [10, 11], q- Szász–Durrmeyer type operators [26], Stancu variant of generalized Baskakov operators [25], and modified Baskakov–Durrmeyer operators [24].

In this work, we highlight the following main notion. The fundamental definitions and characteristics of Bernstein operators are covered in the first part. In the second part, we employ the shifted knot parameters to construct a new family of generalized α-Bernstein operators, including the Stancu–Kantorovich variation. We demonstrate that these new operators are essential to the theory of uniform approximation. In the third, fourth, and fifth sections, we examine the new operators’ shape-preserving features, rate of convergence, and several direct theorems.

Recently, the authors have developed the Stancu variation of Bernstein–Kantorovich operators based on the shape parameter α (fixed real) by [20] for the set of all continuous functions defined on \([0,1]\).

$$ \mathcal{J}_{s,\alpha}^{s_{1},t_{1} }(g;z)=(s+1+t_{1}) \sum _{i=0}^{s}R_{s, \alpha}^{\ast}(z) \int _{\frac{i+s_{1}}{s+1+t_{1}}}^{ \frac{i+1+s_{1}}{s+1+t_{1}}}g(t)\mathrm{d}t, $$


$$\begin{aligned} R_{s,\alpha}^{\ast}(z) =&\binom{s-2}{i}(1-\alpha )z^{i} \left (1-z \right )^{s-i-1} +\binom{s-2}{i-2}(1-\alpha )z^{i-1} \left (1-z \right )^{s-i} \\ +&\binom{s}{i}\alpha z^{i} \left (1-z\right )^{s-i}, \end{aligned}$$

and the parameters satisfy the condition \(0\leq s_{1}\leq t_{1}\).

2 Construction of operators

We offer an extension of Stancu type α-Bernstein–Kantorovich operators in this section, exploring some approximation results through the use of shifted knots. Let \(1\leq p<\infty \), \(\mathcal{I}_{s}=[\frac{\zeta _{2}}{\varkappa _{2}+1+s}, \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}]\) and \(s\geq 2\), \(s\in \mathbb{N}\). Given \(\mathcal{J}_{s,\alpha}^{\ast }: L_{p}[0,1]\rightarrow L_{p}( \mathcal{I}_{s})\), we define shifted knots of α-Bernstein–Kantorovich–Stancu type polynomials (5) as follows: For every \(g \in L_{p}[0,1]\) and any fixed real α, we write

$$ \mathcal{J}_{s,\alpha}^{\ast }(g;z)=(\varkappa _{1}+1+s)\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \sum _{i=0}^{s} \mathcal{Q}_{s,\alpha}^{\ast }(z) \int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t, $$

where \(\frac{\zeta _{2}}{\varkappa _{2}+1+s}\leq z \leq \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}\), \(\zeta _{i}\), \(\varkappa _{i} \) (\(i=1,2\)) are positive real numbers, indeed \(0\leq \zeta _{2} \leq \zeta _{1} \leq \varkappa _{1} \leq \varkappa _{2} \). It is very clear to note that if \(\zeta _{2} =\varkappa _{2}=0\) then the α-Bernstein–Stancu variant of Kantorovich polynomial is given in [20]. And in case of \(\zeta _{1}=\zeta _{2} =\varkappa _{1}=\varkappa _{2}=0\) the classic α-Bernstein–Kantorovich polynomial is obtained in [19] and \(\mathcal{Q}_{s,\alpha}^{\ast }(z)\) is given as follows:

$$\begin{aligned} \mathcal{Q}_{s,\alpha}^{\ast }(z) =&\binom{s-2}{i}(1-\alpha )\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i-1} \\ +&\binom{s-2}{i-2}(1-\alpha )\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i-1} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i} \\ +&\binom{s}{i}\alpha \left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right )^{i} \left (\frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z \right )^{s-i}. \end{aligned}$$

Our motive to construct the Stancu type α-Bernstein–Kantorovich shifted knot operators gives a valuable research path to a researcher in the field of approximation theory. The researcher can use the shifted knot operators with a shape parameter \(\alpha \in [0,1]\) in various Bernstein type operators and can explore them to get a better observation and more flexibility. For example, in our future work we commit to apply these operators to the Bernstein operators by Bézier bases function. For more related results and applications of Bernstein type and shifted knot type operators, we refer to [10, 11, 13, 29]. Moreover, the Bernstein and Bernstein–Stancu polynomials are used in many branches of mathematics and computer science (see [8, 18]).

The primary goal of this paper is to use the integral modulus of continuity and the modulus of continuity to study the approximation properties of operators (6). Ultimately, we derive the convergence of operators (6) using Peetre’s K-functional and Lipschitz maximal functions. Let us do some simple manipulation here, so we take

$$\begin{aligned}& J_{1}=\sum _{i=0}^{s}\binom{s-2}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{s+\varkappa _{2}}-z\right )^{s-i-1}\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t,\\& J_{2}=\sum _{i=0}^{s}\binom{s-2}{i-2}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i-1} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i}\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t. \end{aligned}$$

If it corresponds to term \(i=s\) in \(J_{1}\) and \(i=0\) in \(J_{2}\), then \(\binom{s-2}{s}=0\) and \(\binom{s-2}{-2}=0\). Thus

$$\begin{aligned}& J_{1}=\sum _{i=0}^{s-1}\binom{s-2}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i-1}\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t,\\& J_{2}=\sum _{i=1}^{s}\binom{s-2}{i-2}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i-1} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i}\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t. \end{aligned}$$

Clearly, replace i by \(i+1\) in \(J_{2}\), then

$$ J_{2}=\sum _{i=0}^{s-1}\binom{s-2}{i-1}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i-1}\int _{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}^{ \frac{i+2+\zeta _{1}}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t. $$

Therefore, it follows that

$$\begin{aligned} J_{1}+J_{2} =&\sum _{i=0}^{s-1}\bigg\{ \binom{s-2}{i}\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t+ \binom{s-2}{i-1}\int _{\frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}^{ \frac{i+2+\zeta _{1}}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t\bigg\} \\ \times & \left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left (\frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i-1}, \end{aligned}$$

where \(\binom{s-2}{i}=\left ( 1- \frac{i}{s-1}\right )\binom{s-1}{i}\) and \(\binom{s-2}{i-1}=\frac{i}{s-1}\binom{s-1}{i}\). Hence we have

$$ J_{1}+J_{2}=\sum _{i=0}^{s-1}\binom{s-1}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i-1}f_{i}, $$


$$ f_{i}=\left ( 1-\frac{i}{s-1}\right )\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t + \frac{i}{s-1}\int _{\frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}^{ \frac{i+2+\zeta _{1}}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t. $$

In addition, we take any function \(g \in L_{p}[0,1]\), then for all \(z\in \mathcal{I}_{s} \), \(s\geq 2\), \(s\in \mathbb{N}\) operators (6) are also calculated as

$$ \mathcal{M}_{s,\alpha}^{\ast }(g;z)=(\varkappa _{1}+1+s)\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \bigg[(1-\alpha )\sum _{i=0}^{s-1} \mathcal{U}_{s,\alpha}^{\ast }f_{i}+ \alpha \sum _{i=0}^{s} \mathcal{V}_{s,\alpha}^{\ast }g_{i}\bigg], $$

where \(f_{i}\) is defined by (8), α is any fixed real and

$$\begin{aligned}& g_{i}=\int _{\frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}g(t)\mathrm{d}t, \\& \mathcal{U}_{s,\alpha}^{\ast }=\binom{s-1}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i-1}, \\& \mathcal{V}_{s,\alpha}^{\ast }=\binom{s}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i}. \end{aligned}$$

Lemma 1

Suppose that the test function \(\chi _{j}(t)=t^{\mu }\) for \(\mu =0,1,2\), then for all \(z \in \mathcal{I}_{s}\) operators (6) have the following identities:

$$\begin{aligned} (1)\quad \mathcal{M}_{s,\alpha}^{\ast }(\chi _{0}(t);z) =&\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+\alpha \left ( \frac{\varkappa _{2}+1+s}{s+1}\right ); \\ (2)\quad \mathcal{M}_{s,\alpha}^{\ast }(\chi _{1}(t);z) =&\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} \frac{1}{2(\varkappa _{1}+1+s)}(1-\alpha ) \\ \times & \bigg[ 2s\left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{3} + (1+2 \zeta _{1})\bigg] \\ +&\left (\frac{\varkappa _{2}+1+s}{s+1}\right ) \frac{1}{2(\varkappa _{1}+1+s)}\alpha \\ \times &\bigg[ s \left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} + (1+2 \zeta _{1})\bigg]; \\ (3)\quad \mathcal{M}_{s,\alpha}^{\ast }(\chi _{2}(t);z) =&\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} \frac{1}{3(\varkappa _{1}+1+s)^{2}}(1-\alpha ) \\ \times &\bigg[3s(s-2) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{2} \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} \\ +& \bigg(3(1+2\zeta _{1})(s-1)+3(2+\zeta _{1}) \bigg) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right ) \left ( \frac{\varkappa _{2}+1+s}{s+1}\right ) \\ +& \left (1+3\zeta _{1}+3\zeta _{1}^{2}\right ) \bigg] \\ +&\left (\frac{\varkappa _{2}+1+s}{s+1}\right ) \frac{1}{3(\varkappa _{1}+1+s)^{2}}\alpha \\ \times &\bigg[ 3s(s-1) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{2} \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} \\ +&3(1+2\zeta _{1})s \left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )+\left (1+3 \zeta _{1}+3\zeta _{1}^{2}\right )\bigg]. \end{aligned}$$


If \(\mu =0\), \(\chi _{0}(t)=1\), then we are able to see that from (9)

$$\begin{aligned} \mathcal{M}_{s,\alpha}^{\ast }(\chi _{0}(t);z) =&(\varkappa _{1}+1+s) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \\ \times & \bigg[(1-\alpha )\sum _{i=0}^{s-1}\mathcal{U}_{s,\alpha}^{ \ast }\bigg\{ \left ( 1-\frac{i}{s-1}\right )\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}\mathrm{d}t +\frac{i}{s-1} \int _{\frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}^{ \frac{i+2+\zeta _{1}}{\varkappa _{1}+1+s}}\mathrm{d}t\bigg\} \\ +& \alpha \sum _{i=0}^{s}\mathcal{V}_{s,\alpha}^{\ast }\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}\mathrm{d}t\bigg] \\ =&\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+ \alpha \left (\frac{\varkappa _{2}+1+s}{s+1}\right ). \end{aligned}$$

For \(\mu =1\), \(\chi _{1}(t)=t\), we get

$$\begin{aligned} \mathcal{M}_{s,\alpha}^{\ast }(\chi _{1}(t);z) =&(\varkappa _{1}+1+s) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \\ \times & \bigg[(1-\alpha )\sum _{i=0}^{s-1}\mathcal{U}_{s,\alpha}^{ \ast }\bigg\{ \left ( 1-\frac{i}{s-1}\right )\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}t\mathrm{d}t +\frac{i}{s-1} \int _{\frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}^{ \frac{i+2+\zeta _{1}}{\varkappa _{1}+1+s}}t\mathrm{d}t\bigg\} \\ +& \alpha \sum _{i=0}^{s}\mathcal{V}_{s,\alpha}^{\ast }\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}t\mathrm{d}t\bigg]. \end{aligned}$$

From a simple calculation we see that

$$\begin{aligned}& \left ( 1-\frac{i}{s-1}\right )\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}t\mathrm{d}t +\frac{i}{s-1} \int _{\frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}^{ \frac{i+2+\zeta _{1}}{\varkappa _{1}+1+s}}t\mathrm{d}t = \frac{1}{ 2(\varkappa _{1}+1+s)^{2}}\left ((1+2\zeta _{1})+ \frac{2si}{(s-1)}\right ),\\& \int _{\frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}t\mathrm{d}t = \frac{1}{ 2(\varkappa _{1}+1+s)^{2}}\left (1+2\zeta _{1}+2i)\right ). \end{aligned}$$

Therefore, we get

$$\begin{aligned} \mathcal{M}_{s,\alpha}^{\ast }(\chi _{1}(t);z) =&(\varkappa _{1}+1+s) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{2(\varkappa _{1}+1+s)^{2}}(1-\alpha ) \\ \times & \bigg[ \sum _{i=1}^{s-1} 2s \binom{s-2}{i-1}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-1-i} \\ +& \sum _{i=0}^{s-1}(1+2\zeta _{1})\binom{s-1}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-1-i}\bigg] \\ +&\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{2(\varkappa _{1}+1+s)^{2}}\alpha \\ \times &\bigg[ \sum _{i=1}^{s}2s \binom{s-1}{i-1}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i} \\ +& \sum _{i=0}^{s}(1+2\zeta _{1})\binom{s}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i}\bigg]; \end{aligned}$$
$$\begin{aligned} \mathcal{M}_{s,\alpha}^{\ast }(\chi _{1}(t);z) =&\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{2(\varkappa _{1}+1+s)}(1-\alpha ) \\ \times & \bigg[ \sum _{i=0}^{s-2}2s \binom{s-2}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i+1} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-2-i} \\ +&(1+2\zeta _{1})\left (\frac{s+1}{\varkappa _{2}+1+s}\right )^{s-1} \bigg] +\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{2(\varkappa _{1}+1+s)}\alpha \\ \times & \bigg[ \sum _{i=0}^{s-1}2s \binom{s-1}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i+1} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-1-i} \\ +& (1+2\zeta _{1})\left (\frac{s+1}{\varkappa _{2}+1+s}\right )^{s} \bigg]; \end{aligned}$$
$$\begin{aligned} \mathcal{M}_{s,\alpha}^{\ast }(\chi _{1}(t);z) =& \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{2(\varkappa _{1}+1+s)}(1-\alpha ) \\ \times & \bigg[ 2s\left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{s+1}{\varkappa _{2}+1+s}\right )^{s-2} + (1+2 \zeta _{1})\left (\frac{s+1}{\varkappa _{2}+1+s}\right )^{s-1} \bigg] \\ +&\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{2(\varkappa _{1}+1+s)}\alpha \\ \times &\bigg[ s \left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{s+1}{\varkappa _{2}+1+s}\right )^{s-1} + (1+2 \zeta _{1})\left (\frac{s+1}{\varkappa _{2}+1+s}\right )^{s}\bigg] \\ =&\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} \frac{1}{2(\varkappa _{1}+1+s)}(1-\alpha ) \\ \times & \bigg[ 2s\left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{3} + (1+2 \zeta _{1})\bigg] \\ +&\left (\frac{\varkappa _{2}+1+s}{s+1}\right ) \frac{1}{2(\varkappa _{1}+1+s)}\alpha \\ \times &\bigg[ s \left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} + (1+2 \zeta _{1})\bigg]. \end{aligned}$$

For \(\mu =2\), \(\chi _{2}(t)=t^{2}\), we obtain

$$\begin{aligned} &\left ( 1-\frac{i}{s-1}\right )\int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}t^{2}\mathrm{d}t + \frac{i}{s-1}\int _{\frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}^{ \frac{i+2+\zeta _{1}}{\varkappa _{1}+1+s}}t^{2}\mathrm{d}t \\ =&\frac{1}{ 3(\varkappa _{1}+1+s)^{3}}\left ( \frac{3s}{(s-1)}i^{2}+ \frac{3(1+2\zeta _{1})(s-1)+3(2+\zeta _{1})}{(s-1)}i+(1+3\zeta _{1}+3 \zeta _{1}^{2})\right ), \end{aligned}$$
$$ \int _{\frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}t^{2}\mathrm{d}t = \frac{1}{ 3(\varkappa _{1}+1+s)^{3}}\left (1+3\zeta _{1}+3\zeta _{1}^{2}+(3+6 \zeta _{1})i+3i^{2})\right ). $$


$$\begin{aligned} \mathcal{M}_{s,\alpha}^{\ast }(\chi _{2}(t);z) =&(\varkappa _{1}+1+s) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{3(\varkappa _{1}+1+s)^{3}}(1-\alpha ) \\ \times & \bigg[\sum _{i=0}^{s-3}3s(s-2) \binom{s-3}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i+2} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-3-i} \\ +& \sum _{i=0}^{s-2}\bigg(3(1+2\zeta _{1})(s-1)+3(2+\zeta _{1}) \bigg) \\ \times & \binom{s-2}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i+1} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-2-i} \\ +& \sum _{i=0}^{s-1}\left (1+3\zeta _{1}+3\zeta _{1}^{2}\right ) \binom{s-1}{i}\left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left (\frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-1-i} \bigg] \\ +&(\varkappa _{1}+1+s)\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{3(\varkappa _{1}+1+s)^{3}}\alpha \\ \times &\bigg[ \sum _{i=0}^{s-2}3s(s-1) \binom{s-2}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i+2} \left ( \frac{s+\zeta _{2}}{\varkappa _{2}+1+s}-z\right )^{s-i-2} \\ +&\sum _{i=0}^{s}\left (1+3\zeta _{1}+3\zeta _{1}^{2}\right ) \binom{s}{i}\left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left (\frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i} \\ +&\sum _{i=0}^{s-1}3(1+2\zeta _{1})s \binom{s-1}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i+1} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i-1}\bigg] \\ =&\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{3(\varkappa _{1}+1+s)^{2}}(1-\alpha ) \\ \times &\bigg[3s(s-2) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{2} \left ( \frac{s+1}{\varkappa _{2}+1+s}\right )^{s-3} \\ +& \bigg(3(1+2\zeta _{1})(s-1)+3(2+\zeta _{1}) \bigg) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right ) \left ( \frac{s+1}{\varkappa _{2}+1+s}\right )^{s-2} \\ +& \left (1+3\zeta _{1}+3\zeta _{1}^{2}\right ) \left ( \frac{s+1}{\varkappa _{2}+1+s}\right )^{s-1}\bigg] \\ +&\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \frac{1}{3(\varkappa _{1}+1+s)^{2}}\alpha \\ \times &\bigg[ 3s(s-1) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{2} \left ( \frac{s+1}{\varkappa _{2}+1+s}\right )^{s-2} \\ +&\left (1+3\zeta _{1}+3\zeta _{1}^{2}\right ) \left ( \frac{s+1}{\varkappa _{2}+1+s}\right )^{s} \\ +&3(1+2\zeta _{1})s \left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{s+1}{\varkappa _{2}+1+s}\right )^{s-1}\bigg]; \end{aligned}$$
$$\begin{aligned} \mathcal{M}_{s,\alpha}^{\ast }(\chi _{2}(t);z) =&\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} \frac{1}{3(\varkappa _{1}+1+s)^{2}}(1-\alpha ) \\ \times &\bigg[3s(s-2) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{2} \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} \\ +& \bigg(3(1+2\zeta _{1})(s-1)+3(2+\zeta _{1}) \bigg) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right ) \left ( \frac{\varkappa _{2}+1+s}{s+1}\right ) \\ +& \left (1+3\zeta _{1}+3\zeta _{1}^{2}\right ) \bigg] \\ +&\left (\frac{\varkappa _{2}+1+s}{s+1}\right ) \frac{1}{3(\varkappa _{1}+1+s)^{2}}\alpha \\ \times &\bigg[ 3s(s-1) \left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{2} \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} \\ +&3(1+2\zeta _{1})s \left (z-\frac{\zeta _{2}}{\varkappa _{2}+1+s} \right ) \left (\frac{\varkappa _{2}+1+s}{s+1}\right )+\left (1+3 \zeta _{1}+3\zeta _{1}^{2}\right )\bigg]. \end{aligned}$$

This completes the proof of Lemma 1. □

Lemma 2

Operators \(\mathcal{M}_{s,\alpha}^{\ast }(. \,;\, .)\) have the central moments as follows:

$$\begin{aligned} (1)\quad \mathcal{M}_{s,\alpha}^{\ast }(\chi _{1}(t)-z;z) =& \mathcal{M}_{s,\alpha}^{\ast }(\chi _{1}(t);z)-z\mathcal{M}_{s,\alpha}^{ \ast }(\chi _{0}(t);z) \\ =&O\left (\frac{1}{s}\right )(z+1); \\ (2)\quad \mathcal{M}_{s,\alpha}^{\ast }((\chi _{1}(t)-z)^{2};z) = & \mathcal{M}_{s,\alpha}^{\ast }(\chi _{2}(t);z)-2z\mathcal{M}_{s, \alpha}^{\ast }(\chi _{1}(t);z) +z^{2}\mathcal{M}_{s,\alpha}^{\ast }( \chi _{0}(t);z) \\ =&O\left (\frac{1}{s^{2}}\right )(z+1)^{2}, \end{aligned}$$

where \(\mathcal{M}_{s,\alpha}^{\ast }(\chi _{j}(t);z) \) for all \(j=0,1,2\) are defined by Lemma 1.

Theorem 1

Let \(z \in \mathcal{I}_{s}\), then for the continuous function g on \([0,1]\), it follows that

$$ \lim _{s\to \infty} \|\mathcal{M}_{s,\alpha}^{\ast }(g;z)-g(z)\|_{C( \mathcal{I}_{s})}=0. $$


Taking into account the equality in Lemma 1, it is easy to write

$$ \lim _{s\to \infty} \max _{z \in \mathcal{I}_{s}} |\mathcal{M}_{s, \alpha}^{\ast }(\chi _{\mu}(t);z)-z^{\mu}|=0, \quad \mu =0,1,2. $$

We are denoting

$$ \mathcal{R}_{s,\alpha}^{\ast}(g;z)=\textstyle\begin{cases} \mathcal{M}_{s,\alpha}^{\ast }(g;z) & \text{if } z\in \mathcal{I}_{s}, \\ g(z) & \text{if } z\in [0,1]\setminus \mathcal{I}_{s} .\end{cases} $$

It is easy to get

$$ \|\mathcal{R}_{s,\alpha}^{\ast}(g;z)-g(z)\|_{C[0,1]} =\max _{ z \in \mathcal{I}_{s}}|\mathcal{M}_{s,\alpha}^{\ast }(g;z)-g(z)|. $$

On the other hand, from (11) and (13) we obviously get

$$ \lim _{s\to \infty} \|\mathcal{R}_{s,\alpha}^{\ast}(\chi _{\mu}(t);z)-z^{ \mu}\|_{C[0,1]}=0, \quad \mu =0,1,2. $$

Applying the well-known Korovkin’s theorem [17] to the sequence of operators \(\mathcal{R}_{s,\alpha}^{\ast}\), from this fact it is easy to see for all \(g\in C[0,1] \) on \([0,1]\)

$$ \lim _{s\to \infty} \|\mathcal{R}_{s,\alpha}^{\ast}(g;z)-g(z)\|_{C[0,1]}=0. $$

Thus, (13) gives us

$$ \lim _{s\to \infty} \max _{ z \in \mathcal{I}_{s}}|\mathcal{M}_{s, \alpha}^{\ast }(g;z)-g(z)|=0, $$

where \(C[0,1]\) is the set of all continuous function g on \([0,1]\). This completes the proof. □

Theorem 2

Let \(g\in L_{p}[0,1]\), \(p \in [1,\infty )\), then operators (6) satisfy

$$ \lim _{s\to \infty} \|\mathcal{M}_{s,\alpha}^{\ast }(g;z)-g(z)\|_{L_{P}( \mathcal{I}_{s})}=0. $$


Theorem 1 is taken into consideration for the proof along with the operators \(\mathcal{R}_{s,\alpha}^{\ast}\) by (12). According to the Luzin theorem, there is a continuous function ϕ on \([0,1]\) such that \(\|g-\phi \|_{L_{p}[0,1]}<\epsilon \) for given \(\epsilon >0\). Let \(L_{p}[0,1]\rightarrow L_{p}[0,1]\) be the operator with (12) and \(\|\mathcal{R}_{s,\alpha}^{\ast}\|\) be the operator norm. Then, for any \(s\in \mathbb{N}\), it is sufficient to demonstrate that there exists a positive number M such that \(\|\mathcal{R}_{s,\alpha}^{\ast}\|\leq M\) to support the conclusions made by Theorem 2. We employ Theorem 1 for this purpose, which states that for any \(\epsilon >0\), there exists a number \(s_{0}\in \mathbb{N}\), \(s\geq s_{0}\) such that \(\|\mathcal{R}_{s,\alpha}^{\ast}(\phi ;z)-\phi (z)\|_{C[0,1]}< \epsilon \).

From these facts, we immediately consider

$$\begin{aligned} \|\mathcal{R}_{s,\alpha}^{\ast}(g;z)-g(z)\|_{L_{p}[0,1]} \leq & \| \mathcal{R}_{s,\alpha}^{\ast}(\phi ;z)-\phi (z)\|_{C[0,1]}+\|g-\phi \|_{L_{p}[0,1]} \\ +&\|\mathcal{R}_{s,\alpha}^{\ast}(g;z)-\mathcal{R}_{s,\alpha}^{\ast}( \phi ;z)\|_{L_{p}[0,1]}. \end{aligned}$$

To get positive S, we apply Jensen’s inequality to operators (6)

$$\begin{aligned} |\mathcal{M}_{s,\alpha}^{\ast }(g;z)|^{p} \leq & \bigg\{ ( \varkappa _{1}+1+s)\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s+1} \sum _{i=0}^{s}\mathcal{Q}_{s,\alpha}^{\ast }(z) \int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}|g(t)|\mathrm{d}t\bigg\} ^{p} \\ \leq & \sum _{i=0}^{s} \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s} \mathcal{Q}_{s,\alpha}^{\ast }(z)\bigg\{ (\varkappa _{1}+1+s) \biggl( \frac{\varkappa _{2}+1+s}{s+1}\biggr) \int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}|g(t)|\mathrm{d}t\bigg\} ^{p} \\ \leq & \sum _{i=0}^{s} \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s} \mathcal{Q}_{s,\alpha}^{\ast }(z)(\varkappa _{1}+1+s)\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{p} \int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}|g(t)|^{p}\mathrm{d}t \\ \leq & \bigg[(1-\alpha )\sum _{i=0}^{s-1}\binom{s-1}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-1-i} \\ +&\alpha \sum _{i=0}^{s}\binom{s}{i}\left (z- \frac{\zeta _{2}}{\varkappa _{2}+1+s}\right )^{i} \left ( \frac{\zeta _{2}+1+s}{\varkappa _{2}+1+s}-z\right )^{s-i} \bigg] \\ \times & \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s} ( \varkappa _{1}+1+s)\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{p} \int _{\frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}|g(t)|^{p}\mathrm{d}t. \end{aligned}$$


$$\begin{aligned} \int _{\frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}|\mathcal{M}_{s,\alpha}^{ \ast }(g;z)|^{p}\mathrm{d}z \leq & \bigg[\sum _{i=0}^{s-1} \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{s} \left ( \frac{s+1}{\varkappa _{2}+1+s}\right )^{s+1}\frac{1}{s+1}(1-\alpha ) \\ +&\sum _{i=0}^{s} \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s} \left (\frac{s+1}{\varkappa _{2}+1+s}\right )^{s+1}\frac{1}{(s+1)} \alpha \bigg] \\ \times &(\varkappa _{1}+1+s)\left (\frac{\varkappa _{2}+1+s}{s+1} \right )^{p} \int _{\frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}|g(t)|^{p}\mathrm{d}t \\ \leq & \left (\frac{\varkappa _{1}+1+s}{s+1}\right ) \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{p-1}\sum _{i=0}^{s} \int _{ \frac{i+\zeta _{1}}{\varkappa _{1}+1+s}}^{ \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}}|g(t)|^{p}\mathrm{d}t \\ \leq & \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{p}\|g(t)\|_{L_{p}[0,1]}^{p}. \end{aligned}$$

In the next, from operators (12), we have the inequality \(\int _{[0,1]\setminus \mathcal{I}_{s}}|g(z)|^{p}\mathrm{d}z \leq \|g\|_{L_{p}[0,1]}^{p} \). Thus we find that

$$ \int _{0}^{1} |\mathcal{R}_{s,\alpha}^{\ast}(g;z)|^{p} \mathrm{d}z \leq \bigg[1+\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{p} \bigg]\|g\|_{L_{p}[0,1]}^{p}. $$

Therefore we can write expression (15)

$$ \|\mathcal{R}_{s,\alpha}^{\ast}(g;z)\|_{L_{p}[0,1]} \leq (2+ \varkappa _{2}) \|g\|_{L_{p}[0,1]} \leq M \|g\|_{L_{p}[0,1]}. $$

From the above fact it follows that, for all \(s\in \mathbb{N}\), there exists a positive M such that \(\|\mathcal{R}_{s,\alpha}^{\ast}\|\leq M\). Therefore, from (14) we deduce that

$$\begin{aligned} \|\mathcal{R}_{s,\alpha}^{\ast}(g;z)-g(z)\|_{L_{p}[0,1]} \leq & \| \mathcal{R}_{s,\alpha}^{\ast}(\phi ;z)-\phi (z)\|_{L_{p}[0,1]} \\ +&\|\mathcal{R}_{s,\alpha}^{\ast}\|\|g-\phi \|_{L_{p}[0,1]}+\|g- \phi \|_{L_{p}[0,1]} \\ \leq & 2\epsilon +\epsilon M. \end{aligned}$$

Similarly, taking into account the above inequality, we also see

$$\begin{aligned} \|\mathcal{R}_{s,\alpha}^{\ast}(g;z)-g(z)\|_{L_{p}[0,1]} = & \bigg( \int _{0}^{1} |\mathcal{R}_{s,\alpha}^{\ast}(g;z)-g(z)|^{p} \mathrm{d}z\bigg)^{\frac{1}{p}} \\ = & \bigg( \int _{\mathcal{I}_{s}} |\mathcal{M}_{s,\alpha}^{\ast}(g;z)-g(z)|^{p} \mathrm{d}z\bigg)^{\frac{1}{p}} \\ = & \|\mathcal{M}_{s,\alpha}^{\ast}(g;z)-g(z)\|_{L_{p}(\mathcal{I}_{s})} \\ \leq & 2\epsilon +\epsilon M. \end{aligned}$$

These explanations give us \(\lim _{s \to \infty} \|\mathcal{M}_{s,\alpha}^{\ast}(g;z)-g(z)\|_{L_{p}( \mathcal{I}_{s})} =0\), this completes the proof of Theorem 2. □

3 Rate of convergence of \(\mathcal{M}_{s,\alpha}^{\ast }\)

Finding the degree of approximation for a series of operators \(\mathcal{M}_{s,\alpha}^{\ast }\) is our goal in this section. Recalling the modulus of continuity of function g (see [3]), we employ \(g\in C[0,1]\), the set of all continuous functions on \([0,1]\), and a positive value \(\delta ^{\ast}\), thus

$$ \omega ^{\ast}(g;\delta ^{\ast})=\sup \{ |g(z_{1})-g(z_{2}) |: z_{1},z_{2} \in [0,1], |z_{1}-z_{2} |\leq \delta ^{\ast} \}. $$

As a result, we express the general estimate theorem developed by Shisha and Mond (see [27]) in terms of the modulus of continuity as follows to ascertain the order of convergence.

Theorem 3

[27] Let \([c,d]\subset [a,b]\) and \(\{L_{s}\}_{s \geq 1}\) be the sequence of positive linear operators from \(C[a,b]\) to \(C[c,d]\).

  1. (1)

    If \(g\in C[a,b]\) and \(z \in [c,d]\), then we have

    $$\begin{aligned} |L_{s}(g;z)-g(z)| \leq & |g(z)| |L_{s}(\chi _{0}(t);z)-1| \\ +& \big\{ L_{s}(\chi _{0}(t);z)+ \frac{1}{\delta ^{\ast}} \sqrt{L_{s}((t-z)^{2};z)} \sqrt{L_{s}(\chi _{0}(t);z)} \big\} \omega ^{\ast}(g;\delta ^{\ast}). \end{aligned}$$
  2. (2)

    If \(g^{\prime }\in C[a,b]\) and \(z \in [c,d]\), then we have

    $$\begin{aligned} |L_{s}(g;z)-g(z)| \leq & |g(z)| |L_{s}(\chi _{0}(t);z)-1| + |g^{ \prime }(z)| |L_{s}(t-z;z)| \\ + &L_{s}((t-z)^{2};z) \big\{ \sqrt{L_{s}(\chi _{0}(t);z)} + \frac{1}{\delta ^{\ast}} \sqrt{L_{s}((t-z)^{2};z)}\big\} \omega ^{ \ast}(g^{\prime };\delta ^{\ast}). \end{aligned}$$

Theorem 4

Let the function g be continuous on \([0,1]\), then for each \(z \in \mathcal{I}_{s} \) operators (6) satisfy the inequality

$$\begin{aligned} |\mathcal{M}_{s,\alpha}^{\ast }(g;z)-g(z)| \leq & \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )\left ( \frac{\varkappa _{2}}{s+1}\right )(1-\alpha ) |g(z)| \\ +& 2\bigg\{ \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1- \alpha )+\alpha \left (\frac{\varkappa _{2}+1+s}{s+1}\right ) \bigg\} \omega ^{\ast}\left (g;\sqrt{\delta _{s,\alpha}^{\ast}(z)} \right ), \end{aligned}$$

where \(\delta _{s,\alpha}^{\ast}(z)= \frac{1}{\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+\alpha \left (\frac{\varkappa _{2}+1+s}{s+1}\right )} \mathcal{M}_{s,\alpha}^{\ast }((\chi _{1}(t)-z)^{2};z)\).


If we utilize Lemma 2 and take into account (1) of Theorem 3, we can write

$$\begin{aligned}& |\mathcal{M}_{s,\alpha}^{\ast }(g;z)-g(z)| \\& \quad \leq |g(z)| | \mathcal{M}_{s,\alpha}^{\ast }(\chi _{0}(t);z)-1| \\& \qquad{} + \big\{ \mathcal{M}_{s,\alpha}^{\ast }(\chi _{0}(t);z)+ \frac{1}{\delta ^{\ast}} \sqrt{\mathcal{M}_{s,\alpha}^{\ast }((\chi _{1}(t)-z)^{2};z)} \sqrt{\mathcal{M}_{s,\alpha}^{\ast }(\chi _{0}(t);z)} \big\} \omega ^{ \ast}(g;\delta ^{\ast}) \\& \quad = \left (\frac{\varkappa _{2}+1+s}{s+1}\right )\left ( \frac{\varkappa _{2}}{s+1}\right )(1-\alpha ) |g(z)| \\& \qquad {}+ \omega ^{\ast}(g;\delta ^{\ast})\bigg\{ \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+\alpha \left ( \frac{\varkappa _{2}+1+s}{s+1}\right ) \\& \qquad {}+ \frac{1}{\delta ^{\ast}}\sqrt{\mathcal{M}_{s,\alpha}^{\ast }(( \chi _{1}(t)-z)^{2};z)}\sqrt{\left (\frac{\varkappa _{2}+1+s}{s+1} \right )^{2} (1-\alpha )+\alpha \left (\frac{\varkappa _{2}+1+s}{s+1} \right )} \bigg\} . \end{aligned}$$

If we choose \(\delta ^{\ast}=\sqrt{\delta _{s,\alpha}^{\ast}(z)}= \frac{1}{\sqrt{\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+\alpha \left (\frac{\varkappa _{2}+1+s}{s+1}\right )} } \sqrt{\mathcal{M}_{s,\alpha}^{\ast }((\chi _{1}(t)-z)^{2};z)}\), then we get the desired result. □

Theorem 5

Let \(z\in \mathcal{I}_{s}\), then for every \(g\in C[0,1]\), it follows that

$$\begin{aligned} |\mathcal{M}_{s,\alpha}^{\ast }(g;z)-g(z)| \leq & \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )\left ( \frac{\varkappa _{2}}{s+1}\right )(1-\alpha )\max _{z \in \mathcal{I}_{s} } |g(z)| \\ +& 2\bigg\{ \left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1- \alpha )+\alpha \left (\frac{\varkappa _{2}+1+s}{s+1}\right ) \bigg\} \omega ^{\ast}\left (g;\sqrt{\tilde{\delta}}\right ), \end{aligned}$$

where \(\tilde{\delta}=\max _{z \in \mathcal{I}_{s} }\delta _{s,\alpha}^{ \ast}(z)\).


We easily obtain the desired result due to the monotonicity of the modulus of continuity. □

Remark 1

The order of the local approximation is estimated by Theorem 4, and the global order is estimated by Theorem 5 when we examine the approximation for each point \(z \in \mathcal{I}_{s}\).

Theorem 6

Let \(g^{\prime}\in C[0,1]\), then for each \(z \in \mathcal{I}_{s} \) we have

$$\begin{aligned} |\mathcal{M}_{s,\alpha}^{\ast }(g;z)-g(z)| \leq & \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )\left ( \frac{\varkappa _{2}}{s+1}\right )(1-\alpha ) |g(z)|+\bigg|O\left ( \frac{1}{s}\right )(1+z) \bigg||g^{\prime}(z)| \\ +&2O\left (\frac{1}{s}\right )\bigg\{ \mathcal{M}_{s,\alpha}^{\ast }( \chi _{0}(t);z) \bigg\} ^{\frac{1}{2}}(z+1) \omega ^{\ast}\left (g^{ \prime};\sqrt{\delta _{s,\alpha}^{\ast}(z)}\right ), \end{aligned}$$

where \(\mathcal{M}_{s,\alpha}^{\ast }(\chi _{0}(t);z)=\left ( \frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+\alpha \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )\) and \(\delta _{s,\alpha}^{\ast}(z)\) is defined in Theorem 4.


We consider (2) of Theorem 3 and Lemma 1; as a result, we can write quickly

$$\begin{aligned} |\mathcal{M}_{s,\alpha}^{\ast }(g;z)-g(z)| \leq & \left ( \frac{\varkappa _{2}+1+s}{s+1}\right )\left ( \frac{\varkappa _{2}}{s+1}\right )(1-\alpha ) |g(z)|+\bigg|O\left ( \frac{1}{s}\right )(1+z) \bigg||g^{\prime}(z)| \\ +&\sqrt{\mathcal{M}_{s,\alpha}^{\ast }((\chi _{1}(t)-z)^{2};z)}\sqrt{ \mathcal{M}_{s,\alpha}^{\ast }(\chi _{0}(t);z)} \\ \times & \bigg\{ 1+\frac{1}{\delta ^{\ast}} \frac{\sqrt{\mathcal{M}_{s,\alpha}^{\ast }((\chi _{1}(t)-z)^{2};z)}}{\sqrt{\mathcal{M}_{s,\alpha}^{\ast }(\chi _{0}(t);z)}} \bigg\} \omega ^{\ast}\left (g^{\prime};\delta ^{\ast}\right ) \\ \leq & \left (\frac{\varkappa _{2}+1+s}{s+1}\right )\left ( \frac{\varkappa _{2}}{s+1}\right )(1-\alpha ) |g(z)|+\bigg|O\left ( \frac{1}{s}\right )(1+z) \bigg||g^{\prime}(z)| \\ +&O\left (\frac{1}{s}\right )\bigg\{ \mathcal{M}_{s,\alpha}^{\ast }( \chi _{0}(t);z) \bigg\} ^{\frac{1}{2}}(z+1) 2 \omega ^{\ast}\left (g^{ \prime};\sqrt{\delta _{s,\alpha}^{\ast}(z)}\right ), \end{aligned}$$

which completes the proof asserted by Theorem 6. □

4 Some direct approximation theorem to \(\mathcal{M}_{s,\alpha}^{\ast }\)

Here, too, we examine the approximation in \(L_{p}\) spaces thanks to some preliminary data. The \(L_{p}\) spaces on \(\mathcal{I}_{s}\) are taken for this purpose for every \(p \in [1,\infty )\) as \(L_{p}(\mathcal{I}_{s})\). Lastly, we derive the corresponding estimate in the \(L_{p}(\mathcal{I}_{s})\) spaces. In fact, the integral modification in terms of modulus of continuity for every \(g\in L_{p}(\Theta _{\varkappa})\) is provided by

$$ \hat{\omega}_{1,p}(g,t)=\sup _{z\in \lbrack 0,1 \rbrack} \sup _{0< \varkappa \leq t}\| g(z+\varkappa )-g(z)\| _{L_{p}( \Theta _{\varkappa})} \quad (1\leq p < \infty ), $$

where \(\| .\| _{L_{p}(\Theta _{\varkappa})}\) denotes the \(L_{p}\) norm over \(\Theta _{\varkappa}=[0,1-\varkappa ]\). To measure the smoothness, we use Peetre’s K-functional, and for this purpose we take \(\mathcal{Z}_{1,p}(\Theta _{\varkappa})=\{ g, g^{\prime} \in L_{p}( \Theta _{\varkappa}): g \text{ is absolutely continuous} \}\). Let \(1\leq p <\infty \), then for any \(g\in L_{p}(\Theta _{\varkappa})\) Peetre’s K-functional is defined as follows:

$$ \mathcal{K}_{p}(g,t)=\inf _{f\in \mathcal{Z}_{1,p}(\Theta _{\varkappa}) }\bigg(\| g-f\| _{L_{p}(\Theta _{\varkappa})}+t \| f^{\prime}\| _{L_{p}(\Theta _{\varkappa})}\bigg). $$

Moreover, for the positive constants \(c_{1}\) and \(c_{2}\), the equivalence of relations between integral modulus of continuity and Peetre’s K-functional is given by the inequality (see [14])

$$ c_{1}\hat{\omega}_{1,p}(g,t)\leq \mathcal{K}_{p}(g,t)\leq c_{2} \hat{\omega}_{1,p}(g,t). $$

Taking into account operators (6) and Lemma 1, let us denote \(\mathcal{M}_{i} =[\frac{i+\zeta _{1}}{\varkappa _{1}+1+s}, \frac{i+\zeta _{1}+1}{\varkappa _{1}+1+s}]\)

$$ \mathcal{T}_{s,\alpha}^{\ast }(. ;z)= \frac{1}{\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+\alpha \left (\frac{\varkappa _{2}+1+s}{s+1}\right )} \mathcal{M}_{s,\alpha}^{\ast }(. ;z) $$


$$ \mathcal{P}_{s,i}^{\ast }(z)= \frac{(\varkappa _{1}+1+s)\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{s} }{\left (\frac{\varkappa _{2}+1+s}{s+1}\right ) (1-\alpha )+\alpha} \mathcal{Q}_{s,\alpha}^{\ast }(z). $$

Theorem 7

Let \(g\in \mathcal{Z}_{1,p}[0,1]\), \(p>1\), then operators \(\mathcal{T}_{s,\alpha}^{\ast }\) by (20) satisfy the inequality

$$ \left \vert \left \vert \mathcal{T}_{s,\alpha}^{\ast }(g;z)-g(z) \right \vert \right \vert _{L_{p}(\mathcal{I}_{s})}\leq 2^{ \frac{1}{p}}\left (\frac{p}{p-1} \right ) \max _{z\in \mathcal{I}_{s}} \bigg( \mathcal{T}_{s,\alpha}^{\ast }\left (\chi _{2}(t);z \right ) \bigg)^{\frac{1}{2}} \left \vert \left \vert g^{\prime}\right \vert \right \vert _{L_{p}[0,1]}, $$

where \(\mathcal{T}_{s,\alpha}^{\ast }\left (\chi _{2}(t);z \right )\) is defined by (20).


For any fixed \(z\in \mathcal{I}_{s} \), we easily get that

$$\begin{aligned} \left \vert \mathcal{T}_{s,\alpha}^{\ast }(g;z)-g(z)\right \vert =& \left \vert \sum _{i=0}^{s} \mathcal{P}_{s,i}^{\ast }(z)\int _{ \mathcal{M}_{i}} \left (g(t)-g(z)\right ) \mathrm{d}t\right \vert \\ \leq & \sum _{i=0}^{s} \mathcal{P}_{s,i}^{\ast }(z)\int _{ \mathcal{M}_{i}} \int _{z}^{t} \left \vert g^{\prime}(\lambda ) \right \vert \mathrm{d}\lambda \mathrm{d}t \\ \leq &\Phi _{g^{\prime}}(z)\sum _{i=0}^{s} \mathcal{P}_{s,i}^{\ast }(z) \int _{\mathcal{M}_{i}} \left \vert t-z\right \vert \mathrm{d}t, \end{aligned}$$

where \(\Phi _{g^{\prime}}(z)=\sup _{t\in [0,1]}\frac{1}{t-z} \int _{z}^{t} \left \vert g^{\prime}(\lambda )\right \vert \mathrm{d}\lambda \) for \(t\neq z\) is the Hardy–Littlewood majorant of \(g^{\prime}\). Applying the well-known Cauchy–Schwarz inequality, we get

$$\begin{aligned} \left \vert \mathcal{T}_{s,\alpha}^{\ast }(g;z)-g(z)\right \vert \leq &\Phi _{g^{\prime}}(z)\left (\sum _{i=0}^{s} \mathcal{P}_{s,i}^{ \ast }(z)\right )^{\frac{1}{2}}\bigg(\sum _{i=0}^{s} \mathcal{P}_{s,i}^{ \ast }(z)\int _{\mathcal{M}_{i}} (t-z)^{2} \mathrm{d}t\bigg)^{ \frac{1}{2}} \\ \leq &\Phi _{g^{\prime}}(z)\max _{z\in \mathcal{I}_{s}}\bigg( \mathcal{T}_{s,\alpha}^{\ast }\left ((\chi _{2}(t);z \right ) \bigg)^{\frac{1}{2}}, \end{aligned}$$

where from the Hardy–Littlewood theorem [30] we get

$$ \int _{0}^{1}\Phi _{g^{\prime}}(z) \mathrm{d}z \leq 2\left ( \frac{p}{p-1} \right )^{p} \int _{0}^{1} \left \vert g^{\prime}(z) \right \vert ^{p} \mathrm{d}z \quad (1< p< \infty ). $$

Thus, for any \(1< p<\infty \), we get that

$$ \left \vert \left \vert \mathcal{T}_{s,\alpha}^{\ast }(g;z)-g(z) \right \vert \right \vert _{L_{p}(\mathcal{I}_{s})} \leq 2^{ \frac{1}{p}}\left (\frac{p}{p-1} \right ) \max _{z\in \mathcal{I}_{s}} \bigg( \mathcal{T}_{s,\alpha}^{\ast }\left ((t-z)^{2};z \right ) \bigg)^{\frac{1}{2}} \left \vert \left \vert g^{\prime}\right \vert \right \vert _{L_{p}[0,1]}. $$


Theorem 8

For any \(g\in L_{p}[0,1]\) with the number \(1< p<\infty \), operators (20) verify the inequality

$$ \left \vert \left \vert \mathcal{T}_{s,\alpha}^{\ast }(g;z)-g(z) \right \vert \right \vert _{L_{p}(\mathcal{I}_{s})}\leq \mathcal{C} \hat{\omega}_{1,p}\left (g, \zeta _{s,\alpha}(z)\right ), $$

where \(\mathcal{C}=2 c_{2}+2^{\frac{1}{p}}\left (\frac{p}{p-1} \right )\) is a positive constant and \(\zeta _{s,\alpha}(z)=\max _{z\in \mathcal{I}_{s}}\bigg( \mathcal{T}_{s,\alpha}^{\ast }\left (\chi _{2}(t);z \right ) \bigg)^{ \frac{1}{2}}\).


Let us denote

$$ \left \vert \left \vert \mathcal{T}_{s,\alpha}^{\ast }(\varphi ;z)- \varphi (z)\right \vert \right \vert _{L_{p}[0,1]}\leq \textstyle\begin{cases} 2\left \vert \left \vert \varphi \right \vert \right \vert _{L_{p}[0,1]} & \text{if } \varphi \in L_{p}[0,1], \\ 2^{\frac{1}{p}}\left (\frac{p}{p-1} \right ) \zeta _{s,\alpha}(z) \left \vert \left \vert \varphi \right \vert \right \vert _{L_{p}[0,1]}& \text{if } \varphi \in \mathcal{Z}_{1,p}[0,1],\end{cases} $$

where \(\zeta _{s,\alpha}(z)=\max _{z\in \mathcal{I}_{s}}\bigg( \mathcal{T}_{s,\alpha}^{\ast }\left (\chi _{2}(t);z \right ) \bigg)^{ \frac{1}{2}}\).

For an arbitrary function \(g\in \mathcal{Z}_{1,p}[0,1]\), the positive linear operators imply that

$$\begin{aligned} \left \vert \left \vert \mathcal{T}_{s,\alpha}^{\ast }(g;z)-g(z) \right \vert \right \vert _{L_{p}(\mathcal{I}_{s})} \leq &\left \vert \left \vert \mathcal{T}_{s,\alpha}^{\ast }(g-\phi ;z)-(g-\phi )(z) \right \vert \right \vert _{L_{p}(\mathcal{I}_{s})} \\ + &\left \vert \left \vert \mathcal{T}_{s,\alpha}^{\ast }(\phi ;z)- \phi (z)\right \vert \right \vert _{L_{p}(\mathcal{I}_{s})} \\ \leq & 2 \bigg( \left \vert \left \vert g-\phi \right \vert \right \vert _{L_{p}[0,1]} + 2^{\frac{1-p}{p}}\left (\frac{p}{p-1} \right ) \zeta _{s,\alpha}(z) \left \vert \left \vert g^{\prime} \right \vert \right \vert _{L_{p}[0,1]}\bigg) \\ \leq & 2 \mathcal{K}_{p}\bigg(g,2^{\frac{1-p}{p}}\left ( \frac{p}{p-1} \right ) \zeta _{s,\alpha}(z) \bigg) \\ \leq & 2 c_{2}\hat{\omega}_{1,p}\bigg(g,2^{\frac{1-p}{p}}\left ( \frac{p}{p-1} \right ) \zeta _{s,\alpha}(z) \bigg) \\ \leq & 2 c_{2}\bigg(1+2^{\frac{1-p}{p}}\left (\frac{p}{p-1} \right )\hat{\omega}_{1,p}\left (g, \zeta _{s,\alpha}(z)\right ) \bigg). \end{aligned}$$


Theorem 9

For an arbitrary function \(g\in C^{2}\lbrack 0,1 \rbrack \), let the auxiliary operators \(\mathcal{R}_{s,\alpha}^{\ast }\) be such that

$$ \mathcal{R}_{s,\alpha}^{\ast }(g;z)=\mathcal{T}_{s,\alpha}^{\ast }(g;z)+g(z)-g \bigg( \mathcal{T}_{s,\alpha}^{\ast }(\chi _{1}(t);z)\bigg). $$

Then, for every \(\phi \in C^{2}\lbrack 0,1 \rbrack \), it follows that

$$ \left \vert \mathcal{R}_{s,\alpha}^{\ast }(\phi ;z)-\phi (z)\right \vert \leq \bigg[\mathcal{T}_{s,\alpha}^{\ast }\left ( (\chi _{1}(t)-z)^{2};z \right )+ \bigg(\zeta _{s,\alpha}^{\ast}(z)-z \bigg)^{2}\bigg] \| \phi ^{\prime \prime }\| , $$

where \(\zeta _{s,\alpha}^{\ast}(z)= \frac{1}{\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+\alpha \left (\frac{\varkappa _{2}+1+s}{s+1}\right )} \mathcal{T}_{s,\alpha}^{\ast }\left (\chi _{1}(t);z\right )\) and \(\mathcal{T}_{s,\alpha}^{\ast }\left (\chi _{1}(t);z\right )\) is defined by (20). In addition, \(C^{2}\lbrack 0,1 \rbrack \) is defined by

$$ C^{2}\lbrack 0,1 \rbrack =\{ \phi : \phi \in C\lbrack 0,1 \rbrack \textit{ such that } \phi ^{ \prime }, \phi ^{\prime \prime } \in C\lbrack 0,1 \rbrack \}. $$


For any \(\phi \in C^{2}\lbrack 0,1 \rbrack \), we easily get \(\mathcal{R}_{s,\alpha}^{\ast }(\chi _{0}(t);z)=1\) and

$$ \mathcal{R}_{s,\alpha}^{\ast }(\chi _{1}(t);z)=\mathcal{T}_{s,\alpha}^{ \ast }(\chi _{1}(t);z)+z-\mathcal{T}_{s,\alpha}^{\ast }(\chi _{1}(t);z)=z. $$

From the Taylor series, we see

$$ \phi (\chi _{1}(t))=\phi (z)+(\chi _{1}(t)-z)\phi ^{\prime }(z)+\int _{z}^{ \chi _{1}(t)}(\chi _{1}(t)-\xi )\phi ^{\prime \prime }(\xi ) \mathrm{d}\xi . $$

By use of the linearity of \(\mathcal{R}_{s,\alpha}^{\ast }\), we get

$$\begin{aligned} \mathcal{R}_{s,\alpha}^{\ast }(\phi ;z)-\phi (z) =&\phi ^{\prime }(z) \mathcal{R}_{s,\alpha}^{\ast }(\chi _{1}(t)-z;z)+\mathcal{R}_{s, \alpha}^{\ast }\bigg(\int _{z}^{\chi _{1}(t)}(\chi _{1}(t)-\xi )\psi ^{ \prime \prime }(\xi )\mathrm{d}\xi ;z\bigg) \\ =&\mathcal{R}_{s,\alpha}^{\ast }\bigg(\int _{z}^{\chi _{1}(t)}(\chi _{1}(t)- \xi )\psi ^{\prime \prime }(\xi )\mathrm{d}\xi ;z\bigg) \\ =&\mathcal{T}_{s,\alpha}^{\ast }\bigg(\int _{z}^{\chi _{1}(t)}(\chi _{1}(t)- \xi )\psi ^{\prime \prime }(\varkappa )\mathrm{d}\xi ;z\bigg) \\ -&\int _{z}^{\zeta _{s,\alpha}^{\ast}(z)}\bigg(\zeta _{s,\alpha}^{ \ast}(z)-\xi \bigg)\phi ^{\prime \prime }(\xi )\mathrm{d}\xi , \end{aligned}$$

where \(\zeta _{s,\alpha}^{\ast}(z)= \frac{1}{\left (\frac{\varkappa _{2}+1+s}{s+1}\right )^{2} (1-\alpha )+\alpha \left (\frac{\varkappa _{2}+1+s}{s+1}\right )} \mathcal{T}_{s,\alpha}^{\ast }\left (\chi _{1}(t);z\right )\). Thus

$$\begin{aligned} | \mathcal{R}_{s,\alpha}^{\ast }(\phi ;z)-\phi (z)| \leq & \bigg|\mathcal{T}_{s,\alpha}^{\ast }\bigg(\int _{z}^{\chi _{1}(t)}( \chi _{1}(t)-\xi )\phi ^{\prime \prime }(\varkappa )\mathrm{d}\xi ;z \bigg) \bigg| \\ +&\bigg|\int _{z}^{\zeta _{s,\alpha}^{\ast}(z)}\bigg(\zeta _{s, \alpha}^{\ast}(z)-\xi \bigg)\phi ^{\prime \prime }(\xi )\mathrm{d} \xi \bigg|. \end{aligned}$$

Since we know

$$\begin{aligned} \bigg|\mathcal{T}_{s,\alpha}^{\ast }\bigg(\int _{z}^{\chi _{1}(t)}( \chi _{1}(t)-\xi )\phi ^{\prime \prime }(\varkappa )\mathrm{d}\xi ;z \bigg) \bigg| \leq & \mathcal{T}_{s,\alpha}^{\ast }\bigg|\bigg( \int _{z}^{\chi _{1}(t)}(\chi _{1}(t)-\xi )\phi ^{\prime \prime }( \varkappa )\mathrm{d}\xi ;z\bigg) \bigg| \\ \leq & \mathcal{T}_{s,\alpha}^{\ast } \int _{z}^{\chi _{1}(t)} \bigg|(\chi _{1}(t)-\xi )\phi ^{\prime \prime }(\varkappa ) \mathrm{d}\xi ;z\bigg)\bigg| \\ \leq & \mathcal{T}_{s,\alpha}^{\ast }\left ( (\chi _{1}(t)-z)^{2};z \right ) \| \phi ^{\prime \prime }\| \end{aligned}$$


$$ \bigg|\int _{z}^{\zeta _{s,\alpha}^{\ast}(z)}\bigg(\zeta _{s, \alpha}^{\ast}(z)-\xi \bigg)\phi ^{\prime \prime }(\xi )\mathrm{d} \xi \bigg|\leq \bigg(\zeta _{s,\alpha}^{\ast}(z)-z \bigg)^{2} \| \phi ^{\prime \prime }\| , $$

we get

$$ | \mathcal{R}_{s,\alpha}^{\ast }(\phi ;z)-\phi (z)| \leq \bigg[\mathcal{T}_{s,\alpha}^{\ast }\left ( (\chi _{1}(t)-z)^{2};z \right )+ \bigg(\zeta _{s,\alpha}^{\ast}(z)-z \bigg)^{2}\bigg] \| \phi ^{\prime \prime }\| . $$

This gives the complete proof of Theorem 9. □

5 Graphical analysis

In this section, we give a numerical example with illustrative graphics with the help of MATLAB.

Example 1

Let \(g(y)=(y-\frac{1}{3})(y-\frac{3}{5})\), \(\xi _{1}=4\), \(\xi _{2}=3\), \(\chi _{1}=1.5\), \(\chi _{2}=4\), and \(s\in \{20,30,110\}\). The convergence of the operator towards the function \(g(y)\) is shown in Fig. 1.

Figure 1
figure 1

Convergence of the operator towards the function \(g(y)\)

From this example, we observe that approximation of function by the operators becomes better when we take larger values of s.

6 Conclusions

It is very clear that for the choices of \(\zeta _{2} =\varkappa _{2}=0\), our new constructed operators reduced to α-Bernstein–Stancu variant of Kantorovich polynomial given by [20]. For the choices of \(\zeta _{1}=\zeta _{2} =\varkappa _{1}=\varkappa _{2}=0\), our new constructed operators reduced to the classical α-Bernstein–Kantorovich polynomial obtained in [19]. Therefore, based on our research, we can conclude that the shifted knot operators defined by equality (6), which we have named our new Bernstein–Kantorovich variation, are an improved version of the previous operators defined by [19, 20]. This article’s major goal is to examine how operators that shifted knots of α-Bernstein–Kantorovich operators (6) in \(L_{p}\) spaces converge on \([0, 1]\).

Data Availability

No datasets were generated or analysed during the current study.


  1. Alotaibi, A., Nasiruzzaman, M., Mohiuddine, S.A.: On the convergence of Bernstein-Kantorovich shifted knots operators by Schurer parameter. Complex Anal. Oper. Theory 18, 4 (2024).

    Article  Google Scholar

  2. Alotaibi, A., Nasiruzzaman, M., Mursaleen, M.: Approximation by Phillips operators via q-Dunkl generalization based on a new parameter. J. King Saud Univ., Sci. 33(4), Article id: 101413 (2021)

    Article  Google Scholar

  3. Altomare, F., Campiti, M.: Korovkin-Type Approximation Theory and Its Applications. de Gruyter, Berlin (2011).

    Book  Google Scholar

  4. Ansari, K.J., Özger, F., Özger, Z.Ö.: Numerical and theoretical approximation results for Schurer–Stancu operators with shape parameter λ. Comput. Appl. Math. 41, Article id: 181 (2022)

    Article  MathSciNet  Google Scholar

  5. Ayman-Mursaleen, M., Heshamuddin, M., Rao, N., Sinha, B.K., Yadav, A.K.: Hermite polynomials linking Szász-Durrmeyer operators. Comput. Appl. Math. 43(4), Article id: 223 (2024)

    Article  Google Scholar

  6. Ayman-Mursaleen, M., Lamichhane, B.P., Kiliçman, A., Senu, N.: On q-statistical approximation of wavelets aided Kantorovich q-Baskakov operators. Filomat 38(9), 3261–3274 (2024)

    MathSciNet  Google Scholar

  7. Ayman-Mursaleen, M., Nasiruzzaman, M., Rao, N., Dilshad, M., Nisar, K.S.: Approximation by the modified λ-Bernstein-polynomial in terms of basis function. AIMS Math. 9(2), 4409–4426 (2024)

    Article  MathSciNet  Google Scholar

  8. Babu, G.J., Canty, A.J., Chaubey, Y.P.: Application of Bernstein polynomials for smooth estimation of distribution and density function. J. Stat. Plan. Inference 105(2), 377–392 (2002)

    Article  MathSciNet  Google Scholar

  9. Bernstein, S.N.: Démonstration du théoréme de Weierstrass fondée sur le calcul des probabilités. Commun. Kharkov Math. Soc. 13, 1–2 (1912)

    Google Scholar

  10. Cai, Q.B.: The Bézier variant of Kantorovich type λ-Bernstein operators. J. Math. Anal. Appl. 2018, Article id: 90 (2018)

    Google Scholar

  11. Cai, Q.B., Lian, B.Y., Zhou, G.: Approximation properties of λ-Bernstein operators. J. Inequal. Appl. 2018, Article id: 61 (2018)

    Article  MathSciNet  Google Scholar

  12. Chen, X., Tan, J., Liu, Z., Xie, J.: Approximation of functions by a new family of generalized Bernstein operators. J. Math. Anal. Appl. 450, 244–261 (2017)

    Article  MathSciNet  Google Scholar

  13. Gadjiev, A.D., Ghorbanalizade, A.M.: Approximation properties of a new type Bernstein-Stancu polynomials of one and two variables. Appl. Math. Comput. 216, 890–901 (2010)

    MathSciNet  Google Scholar

  14. Johnen, H.: Inequalities connected with the moduli of smoothness. Mat. Vesn. 9(24), 289–303 (1972)

    MathSciNet  Google Scholar

  15. Kajla, A., Mohiuddine, S.A., Alotaibi, A.: Approximation by α-Baskakov-jain type operators. Filomat 36(5), 1733–1741 (2022)

    Article  MathSciNet  Google Scholar

  16. Kajla, A., Mohiuddine, S.A., Alotaibi, A.: Durrmeyer-type generalization of μ-Bernstein operators. Filomat 36(1), 349–360 (2022)

    Article  MathSciNet  Google Scholar

  17. Korovkin, P.P.: Linear Operators and Approximation Theory. Hindustan Publishing Corporation, Delhi (1960)

    Google Scholar

  18. Matsuoka, M.: An application of Bernstein polynomials in PAC model. In: Algorithmic Learning Theory. Lecture Notes in Comput. Sci., vol. 743, pp. 220–228. Springer, Berlin (1993)

    Chapter  Google Scholar

  19. Mohiuddine, S.A., Acar, T., Alotaibi, A.: Construction of a new family of Bernstein-Kantorovich operators. Math. Methods Appl. Sci. 40(18), 7749–7759 (2017)

    Article  MathSciNet  Google Scholar

  20. Mohiuddine, S.A., Özger, F.: Approximation of functions by Stancu variant of Bernstein-Kantorovich operators based on shape parameter. Rev. R. Acad. Cienc. Exactas Fís. Nat., Ser. A Mat. 114, Article id: 70 (2020)

    Article  MathSciNet  Google Scholar

  21. Mursaleen, M., Ansari, K.J., Khan, A.: Approximation properties and error estimation of q-Bernstein shifted operators. Numer. Algorithms 84, 207–227 (2020)

    Article  MathSciNet  Google Scholar

  22. Özger, F.: On new Bézier bases with Schurer polynomials and corresponding results in approximation theory. Commun. Fac. Sci. Univ. Ank. Sér. A1 Math. Stat. 69(1), 376–393 (2020)

    MathSciNet  Google Scholar

  23. Özger, F., Srivastava, H.M., Mohiuddine, S.A.: Approximation of functions by a new class of generalized Bernstein–Schurer operators. Rev. R. Acad. Cienc. Exactas Fís. Nat., Ser. A Mat. 114, Article id: 173 (2020)

    Article  MathSciNet  Google Scholar

  24. Rao, N., Nasiruzzaman, M., Heshamuddin, M., Shadab, M.: Approximation properties by modified Baskakov–Durrmeyer operators based on shape parameter-α. Iran. J. Sci. Technol., Trans. A, Sci. 45, 1457–1465 (2021)

    Article  MathSciNet  Google Scholar

  25. Rao, N., Wafi, A.: Stancu-variant of generalized Baskakov operators. Filomat 31(9), 2625–2632 (2019)

    Article  MathSciNet  Google Scholar

  26. Rao, N., Wafi, A., Acu, A.M.: q- Szász–Durrmeyer type operators based on Dunkl analogue. Complex Anal. Oper. Theory 13, 915–934 (2019)

    Article  MathSciNet  Google Scholar

  27. Shisha, O., Bond, B.: The degree of convergence of sequences of linear positive operators. Proc. Natl. Acad. Sci. USA 60, 1196–1200 (1968)

    Article  MathSciNet  Google Scholar

  28. Stancu, D.D.: Approximation of functions by a new class of linear polynomial operators. Rev. Roum. Math. Pures Appl. 13, 1173–1194 (1968)

    MathSciNet  Google Scholar

  29. Sucu, S., Ibikli, E.: Approximation by means of Kantorovich-Stancu type operators. Numer. Funct. Anal. Optim. 34(5), 557–575 (2013)

    Article  MathSciNet  Google Scholar

  30. Zygmund, A.: Trigonometric Series I, II. Cambridge University Press, Cambridge (1959)

    Google Scholar

Download references


The authors extend their appreciation to the Deanship of Scientific Research at University of Tabuk for Funding this work through Research no. S-0157-1443.

Author information

Authors and Affiliations



Author 1: wrote the main manuscript text Authors 2,3,4: read and reviewed the manuscript

Corresponding author

Correspondence to Md. Nasiruzzaman.

Ethics declarations

Competing interests

The authors declare no competing interests.

Additional information

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Rights and permissions

Open Access This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article’s Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article’s Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit

Reprints and permissions

About this article

Check for updates. Verify currency and authenticity via CrossMark

Cite this article

Nasiruzzaman, M., Dilshad, M., Albalawi, B.M.E. et al. Approximation properties by shifted knots type of α-Bernstein–Kantorovich–Stancu operators. J Inequal Appl 2024, 85 (2024).

Download citation

  • Received:

  • Accepted:

  • Published:

  • DOI:

Mathematics Subject Classification
